Over 100 years of bicycle DNA. Our family stands for courage, experience and vision - qualities that live on in every Raymon bike. With this tradition behind us, we create bikes that offer exactly what you are looking for on and off road.
Bicycle specifications
E-bike system
Engine:
Bosch Performance Line CX, 250/600 W, 85 Nm
Bicycle computer:
integrated in display
Remote:
Bosch Purion 200, Bluetooth
Battery:
Bosch PowerTube, 600 Wh, 36 V
Charger:
Bosch Charger, 4 A
Frame and suspension
Frame:
Aluminium 6061, removeable battery, boost
Fork:
SR Suntour MOBIEA32 LO, coil, 75mm, tapered
Drivetrain
Drivetrain type:
External
Rear derailleur:
Shimano Essa, RD-U2000, 8-speed
Shifters:
Shimano SL-M315, Rapidfire Plus
Crankset:
Raymon, Narrow Wide, 40T, CG
Cassette:
Shimano CS-HG400-8, 11-45T
Brake system
Brakes:
Tektro Vela, 2-piston, Hydraulic Disc
Cockpit
Handlebar:
Raymon Riser 31,8 mm, Sweep: 15 °, Rise: 30 mm
Stem:
Raymon 31.8, Ahead, adjustable
Grips:
Raymon Ergo, lock on
Headset:
FSA CR, Internal Cable Routing
Wheels
Wheelset:
Raymon VR24/DT210, 15x100/12x148 mm
Front tire:
Schwalbe Advancer Hybrid, Reflex 57-622, 29x2.25
Tires:
Schwalbe Advancer Hybrid, Reflex 57-622, 29x2.25
Saddle and components
Saddle:
Raymon MIMA VM fit
Seat post:
Raymon, 34,9 mm
Seat post clamp:
38,9, hex screw
Accessories
Kickstand:
Ursus MOOI, KSA40, adjustable
Carrier:
Raymon, MIK HD, 27 kg
Front light:
Litemove HKSE-70, 70 lx
Rear light:
Spanninga Glow
Weight and dimensions
Maximum load (rider+bicycle):
130 kg
The Performance Line CX takes riding dynamics and agility to a whole level. It is powerful, light and quiet. Ten years of experience and countless trail rides all over the world have gone into its further development. The Performance Line CX combines power, dynamics, efficiency and altitude. 85-600-340: These values represent the ideal balance between performance and riding fun in relation to wear and range. 85 Nm Max. Torque; 600 W Max. motor power; 340 % Max. support factor.
