E-bike Raymon Metmo Select CB 27.5" 2025 timeless-moss
Alternative products
Description - E-bike Raymon Metmo Select CB 27.5" 2025 timeless-moss
Over 100 years of bicycle DNA. Our family stands for courage, experience and vision - qualities that live on in every Raymon bike. With this tradition behind us, we create bikes that offer exactly what you are looking for on and off road.
Bicycle specifications
E-bike system
Engine:
Yamaha PW-CE CB, 250 W, 50 Nm
Bicycle computer:
integrated in display
Remote:
Yamaha Display A2, LCD, Micro-USB
Battery:
504 Wh, 36 V
Charger:
Charger, 4 A
Frame and suspension
Frame:
Aluminium 6061, removeable battery
Fork:
SR Suntour XCM32-ATB, coil, 80 mm, tapered
Drivetrain
Speeds:
8
Drivetrain system:
1x8
Drivetrain type:
Internal
Shifters:
Shimano Nexus, SL-C6000, Revoshift
Crankset:
Raymon, 38T
Rear sprocket:
Shimano SM-GEAR, 19T
Chain:
KMC Z1eHX
Brake system
Brakes:
Shimano BR-MT200, 2-piston, Hydraulic Disc, coaster brake
Cockpit
Handlebar:
Raymon Ergo 31,8 mm, Sweep: 35 °, Rise: 25 mm
Stem:
Raymon 31.8, Ahead, adjustable
Grips:
Raymon Ergo, lock on
Headset:
FSA NO.55R/57SC/57B
Wheels
Wheel size:
27.5"
Wheelset:
Raymon VR18/Shimano QC300/C6001-8CD
Front tire:
Continental eContact Plus, Reflex, 55-584, 27.5x2.20
Tires:
Continental eContact Plus, Reflex, 55-584, 27.5x2.20
Saddle and components
Saddle:
Raymon MIMA VM fit
Seat post:
Raymon, 34,9 mm
Seat post clamp:
38,9, hex screw
Accessories
Mudguards:
SKS PET
Kickstand:
Raymon, KSA18, adjustable
Carrier:
Raymon, MIK, 25 kg
Front light:
AXA Nxt 30, 30 lx
Rear light:
AXA Juno E
Weight and dimensions
Weight:
27,9 kg
Maximum load (rider+bicycle):
130 kg
PWseries CE Features
Yamaha Motor focused the PWseries CE development efforts in the achievement of natural enjoyable ride. Measures taken include: weight and noise reduction, implementation of the Automatic Support Mode and walk assist.
Lightweight
The PWseries CE lightweight, starting at 2.9kg, adds to the unit's natural assist setting to provide an enjoyable ride. The rider should feel a light, swift handling while on the move and noticeable lightweight while pushing the bike around.
Most Quiet Drive Unit
Yamaha Motor strived to offer its most quiet drive unit to date, reducing noise significantly. With the PWseries CE, early morning rides in the park closest to you instantly become a relaxing nature-immersive experience.
Compact Design
The ideal of unity of power assist unit and bike is also perceivable to the eye. The PWseries CE compact design gives a sharp and overall clean look to the bike.
Automatic Support Mode
The quest for an ever more natural e-Bike ride goes beyond hardware improvements. The PWseries CE uses Yamaha Motors extensive software setting know-how in its Automatic Support Mode. The system copes swiftly with constant changes in riding conditions - think of those upwind rides, and constant stops and starts for traffic lights - by automatically selecting the most appropriate support mode. The Automatic Support Mode also provides strong and smooth support for every start. It can be deactivated at the will of the rider.
Walk Assist
Handling an e-Bike should not be a burden when you are off it. The walk assist in the PWseries CE comes in handy when pushing the bike, even up steep slopes or when the bike is carrying heavy loads.
Technical Specifications
| Drive Unit | Center Motor |
|---|---|
| Weight | 2.9 kg |
| Rated Output | 250 W |
| Max. Torque | 50 Nm |
| Max. Assist Speed | 25 km/h |
| Assist Mode | HIGH, STD, ECO, +ECO |
| Automatic Support Mode | Yes |
